DMLV Submersible Vortex Pumps

Submersible pumps with non clog vortex impellers  and double
row lower bearings for reliability. Suitable for waste water
containing soft solids, raw sewage, storm water, etc.

Specifications

  • Submersible pump with vortex impeller
  • Maximum solids handling: 80 or 100 mm
  • Maximum liquid temperature: 40 °C
  • Maximum submergence: 8 m



Materials

  • Pump casing: Cast Iron
  • Impeller: Cast Iron
  • Shaft: 403 Stainless Steel
  • Motor frame: Cast Iron
  • Fasteners: 304 Stainless Steel
  • Mechanical seal: Double mechanical seal in oil chamber;

                                 Silicon Carbide lower faces,
                                 Carbon/Ceramic upper faces.


Motor Data

  • Air filled, dry submersible, 4 pole, 50 Hz
  • Star-Delta (DOL for 2.2 kW)
  • Insulation class F
  • IP68 protection
  • 3 Phase - 400 Volt

Range

  • 80 to 100mm Ø discharge
  • 2.2 to 22 kW - 3 Phase (manual only)
